Description
Product details
Application: These washing line are ideally suited for: • A plastic washing line specifically designed for processing crushed HDPE/PP pipe waste granules (approximately 6-10mm) contaminated with soil, mud, dust, and air pollution residues. • The line prioritizes washing and drying the material for efficient recycling of HDPE, PP & PVC flakes with capacity of 40-60kg/hr Specification: • Input Material: Crushed PET flakes (approximately 6-10mm) • Contaminants: Soil, mud, dust, and air pollution residues • Functionality: Washing, drying, Optional (separation of HDPE and PP) • Water Usage: Recirculating water system (minimizes water consumption) • Cleaning Agents: No soap or chemicals required • Output: Clean, dry HDPE flakes collected in a dedicated unit/silo • Power Requirement: 380V, 3 phase, 50 Hz • Compliance: CE certification and EU declaration of conformity • Documentation: User manual will be provided in Danish SILENT FEATURES: • Modular Design: Allows for future expansion and can be customization to separate HDPE & PP Particles using Floating Tank. • Energy Efficiency: Recirculating water system and optimized motor usage minimize energy consumption. • Low Maintenance: Easy access to components for cleaning and maintenance. • Automated Operation: Minimizes manual intervention and ensures consistent processing. • Environmentally Friendly: Reduces water usage and eliminates chemical cleaning agents. DESIGN PARAMETERS WITH STANDARD SUPPLY: 1. HOT WASH TANK: Size : Ø1200 x 2200 x 5mm Thk. Agitator Blade : 65 x 1000 x 16mm Thk. Coil Size : Ø32NB x 4mm Thk Coil Make : SS 304 Material : SS 304 Gear Box : Bonfiglioli Make. Motor : 5 HP Crompton Make Drive : Belt Drive Qty : 1Nos 2. Inclined Screw Conveyor Ø 220 x 4Mtr Long. Type : S.S 304 Pipe with Screw Assembly & Leg support. Material to be handled : Flaks Pipe size : Ø 220 x 4000 mm Long Designed Capacity : 750 kg /Hr. Gear Box : Bonfiglioli Make. Motor : 2 HP Crompton Make Drive Type : Chain Coupling ¾” pitch.
